Explosion-proof series
Explosion-proof ball machine
PB-6080
Features
The shell is made of 304 stainless steel;
Protection class IP68;
1 3/4" outlet hole;
Rotation speed horizontal 0~240° /S, vertical 0~90° /S;
Rotation Angle 360° horizontal, 90° vertical;
High quality optical glass, high transmittance, image without distortion;
Optional multi-area shield function, high-speed ball 256 preset bits, 4 cruise tracks;
All-round head, no blind spot monitoring, positioning accuracy 0.1°;
Dimensions: ?218*273mm
Input voltage: AC24V (DC12V optional)
Weight: 10Kg
Operating temperature: -20℃ ~+60℃
Haikang, Dahua, SONY and other specifications automatically adapt.
Parameters
Explosion-proof mark: Ex db II C T6 Gb/Ex tb III C T85℃ Db
Explosion-proof Certificate Number: GYB21.1049X
Outline Dimensional Drawing
